175L Dewar Bottle Liquid Nitrogen Oxygen LNG Cryogenic Cylinder Vertical Insulated Dewar Tank

Volume(L):175
Size(mm):505X1485
Empty weight(kg):111
Working Pressure(MPa):1.4
Level gauge:Float type
Maximum filling weight(kg):LOX(177)/LAR(217)/LN2(126)/LCO2(/)/LNG(66)
  • 175L Dewar Bottle Liquid Nitrogen Oxygen LNG Cryogenic Cylinder Vertical Insulated Dewar Tank
  • 175L Dewar Bottle Liquid Nitrogen Oxygen LNG Cryogenic Cylinder Vertical Insulated Dewar Tank
  • 175L Dewar Bottle Liquid Nitrogen Oxygen LNG Cryogenic Cylinder Vertical Insulated Dewar Tank
  • 175L Dewar Bottle Liquid Nitrogen Oxygen LNG Cryogenic Cylinder Vertical Insulated Dewar Tank
  • 175L Dewar Bottle Liquid Nitrogen Oxygen LNG Cryogenic Cylinder Vertical Insulated Dewar Tank
  • 175L Dewar Bottle Liquid Nitrogen Oxygen LNG Cryogenic Cylinder Vertical Insulated Dewar Tank
Description
DPL series dewar cylinder is a kind of high-performance vacuum insulated cylinder, which is used to store and transport cryogenic liquid oxygen, nitrogen, argon, carbon dioxide, liquefied natural gas ,etc. It can be used for road transportation of cryogenic liquid, and also can be used for on-site storage and supply. Long storage time, wide range of applications .


* Vaporizer installed inside can supply 10m3/h gas continuously
* Adopt the international standard connectors, all valves are imported brands.
* Customization
* Damping ring design to make sure the transportation safely
* Are widely used in the industries of Chemical /machinery /shipbuilding/ hospital /electronic /medical /material /energy /research/fish-heat preservation, etc.
We are the best ideal for liquid nitrogen, oxygen, argon, CO2 or nitrous oxide and the different sizes, pressure.


It has stainless steel bottle construction with thick, dent-resistant outer shell,plus durable inner-vessel support system and heavy-duty footring and large diameter handling ring with four supports.

Type:DP-175/1.4II

Volume(L):175

Effective volume(L):160

Size(mm):505X1485

Working Pressure(MPa):1.4

Set pressure of main safety value(MPa):1.6

Set pressure of bursting discset(MPa):2.8

Empty weight(kg):111

Maximum filling weight(kg):LOX(177)/LAR(217)/LN2(126)/LCO2(/)/LNG(66)

Level gauge:Float type

The base style:Frame style

Gas delivery rate:10m3/h
More Product or Size,please contact us for Inquiry!
